Description
Millable Applications
Discover the Range of Applications You Can Create with Your DWX-43W
Whether you’re crafting dental crowns, bridges, or custom abutments, this advanced technology ensures exceptional quality and consistency in every piece.
With the DWX-43W, you can explore a wide range of dental applications, all produced with the highest standards of accuracy and detail.
Automated Maintenance Features Save Time
Save valuable time with the DWX-43W’s automated maintenance features.
Auto-rinse prevents contamination, sticking, and drying, maintaining clean and efficient production.
Automatic correction ensures accurate milling while saving hours of manual calibration.
With an improved waterflow system, milling burs and other device parts stay cleaner for longer with no need for costly filter consumables.
In addition, the included Virtual Panel software (VPanel for DWX) seamlessly provides maintenance oversight and output performance control.
Specification:
| Milable material* | Glass ceramics, Titanium alloy, Composite resins, PMMA, PEEK, Sintered zirconia | |
| Number of adapters housed | 6 | |
| Operating speed | XYZ axis: | 6 to 1,800 mm/min. (0.24 to 70.9 in./min.) |
| Spindle motor | Brushless DC Motor | |
| Spindle speed | 15,000 to 60,000 rpm | |
| Rotary axis travel angle | A axis | ±360° |
| Attachable bur | Shank diameter: 3 mm | |
| Length | 40-55 mm | |
| Compatible compressed air | 0.18 to 0.22 MPa | |
| Interface | USB, Ethernet | |
| Control command set | RML-1, NC code | |
| Power requirements | AC 100 to 240 V ± 10%, 50/60 Hz (overvoltage category: II, IEC 60664-1), 2.1A | |
| Power consumption | Approx. 190 W | |
| Operating noise | During operation | 70 dB(A) or less (when not cutting) |
| During standby | 48 dB(A) or less | |
| External dimensions | Width | 19.0 in (482 mm) |
| Depth | 22.0 in (560 mm) | |
| Height | 23.6 in (600 mm) | |
| Weight | 135 lbs. (61 kg) | |
| Installation environment | Altitude | Up to 6,562 ft. (2,000m) |
| Temperature | 41 to 82° F 5 to 28° C |
|
| Humidity | 35 to 80%RH (no condensation) | |
| Ambient pollution degree | 2 (as specified by IEC 60664-1) | |
| Short-term temporary overvoltage | 1,440 V | |
| Long-term temporary overvoltage | 490 V | |
| Included items | Power cord, USB cable, detection pin, regulator, Safety Precautions, Quick Access Guide, automatic correction jig, hexagonal screwdriver, Multi-pin Clamp, etc | |
| Operating system | Windows 11, Windows 10 (64-bit) | |
| USB cable | Use the included USB cable | |
