Description
| Millable material*1 | Zirconia, Wax, PMMA, Gypsum, PEEK, PEKK, Glass-fiber-reinforced resin, Composite resin, CoCr sinter metal, Polycarbonate | |
| Loadable workpiece shape | External Diameter | 98.5 mm |
| Max Height | 60 mm | |
| Step | 10 mm | |
| Pin Type Diameter | 6 mm | |
| Number of adapters housed | 15 | |
| Operating speed | XY axis: | 3,000 mm/min (118.11 in./min) max,, Z: 2,700 mm/min (106.29 in./min) max |
| Spindle motor | Brushless DC Motor | |
| Spindle speed | 6,000 to 30,000 rpm | |
| Rotary axis travel angle | A axis | ±360° |
| B axis | ±35° | |
| Number of burs housed | 15 | |
| Attachable bur | Shank diameter | 4 mm |
| Length | 40-55 mm | |
| Compatible compressed air | 0.4 MPa | |
| Interface | USB | |
| Control command set | RML-1, NC code | |
| Power requirements | 100 to 240 VAC ± 10%, 50/60 Hz (overvoltage category: II, IEC 60664-1),1.8 A | |
| Power consumption | Approximately 170 W | |
| Operating noise | During operation | 70 dB(A) or less (when not cutting) |
| During standby | 48 dB(A) or less | |
| External dimensions | Width | 21.85 in (555 mm) |
| Depth | 28.54 in (725 mm) | |
| Height | 27.76 in (705 mm) | |
| Weight | 231.49 lbs. (105 kg) | |
| Installation environment | Altitude | Up to 6,562 ft. (2,000m) |
| Temperature | 41 to 104° F 5 to 40° C |
|
| Humidity | 35 to 80% (no condensation) | |
| Ambient pollution degree | 2 (as specified by IEC 60664-1) | |
| Short-term temporary overvoltage | 1,440 V | |
| Long-term temporary overvoltage | 490 V | |
| Included items | Power cord, power plug adapter, USB cable, Safety Precautions, Quick Access Guide, detection pin, automatic correction jig, torque screwdriver, T-shaped hexagonal screwdriver, L-shaped hexagonal wrench, collet attaching/detaching jig, milling bur holder, milling bur positioner, regulator, adapter ID labels, standard adapter, open edge adapter, adapter rack, pin-type workpiece adapter, milling burs, etc. | |
| Operating system | Windows 11, Windows 10 (64-bit versions) | |
| USB cable | Use the included USB cable | |
