Description
3μm accuracy repeatabilityMicron-level precision control in the machining area
Highly accurate C-shaped holder designed for secure positioning Supports 98 mm
diameter discs Compatible with 10–40 mm thickness materials Equipped with
high-precision holders for glass ceramic blocks
B-Axis works between -30°~92° to meet customized milling need
The Assembly Accuracy of each axis maintains precision within 0.01 mm
| Dimensions (LxWxH): | 550x530x750mm |
| Weight: | Approximately 130kg |
| Input Voltage: | Single-Phase AC 220V |
| Spindle power: | 2.5kw |
| Axis quantity: | 5 |
| Rotation Range: | +-360° / -30~92° |
| Milling Mode: | Dry & Wet |
| Milling Max speed: | 60,000rpm |
| Precision | <0.01mm |
| Bur Capacity: | 14 |
| Motor Type | Servo Motor |
| Spindle Cooling: | Water Cooling |
| Processing Materials: | Zirconia,Wax, PMMA ,Titanium Disc, Glass Ceramic, Resin,
Pre-milled Titanium Column |
| Avg Milling Times: | Zirconia：8mins Wax：3mins |
| Air pressure Range | 0.4~0.8 MPa |
| Holder | C- Shaped; holding 3 glass ceramic blocks; holding 3 pre-milled Titanium coloumn |
Accessories
1- Inner Hexagon Spanner 2- Collet Chuck Remover 3- Milling Machine
5- Spare Screws
6- Collet Chuck Cleaning Brush
9- Holder for Titanium Column 10- 8P Pipe Tee
13- Wax Blank
14- Test Alum. Column
7- Brush
11- Power Cable
4- Oil-water Separator
8- Holder for Glass Ceramic Block
12- Water Pump Cable
15- Testcube 16- Milling Bur 17- Compressed Air hose
18- Water Hose 19- Cooling Water Tank Installation
20- U Disk
21- Drain Hose
22- Open-ended Spanner, Fastener 23- Water Chiller 24- Signal Cable for Water Chiller
25- Quality Certificate
