MESA-MAGNUM CERAMIC S

AGKEM’s MESA Magnum Ceramic S is formulated with nickel, chromium, molybdenum, and silicon. It provides a specified yield strength of 360 MPa, Vickers hardness of 188 HV10, and a modulus of elasticity of 190 GPa.

Key Features

63% nickel and 25% chromium
188 HV10 Hardness
190 GPa Elastic Modulus
9% Elongation at Fracture
Maximum Firing Temperature of 900°C
Specified Ion Release

Enquire Now!

Description
Reviews (0)

Description

Composition in %
Nickel (Ni) 63 % Chrome (Cr) 25 % Molybdenum (Mo) 9 % Silicon (Si) 2 %

Physical and mechanical features

Solidus-liquidus temperature	1312 ÷ 1369 °C
Thermal expansion coefficient	(25 ÷ 500 °C) 13,7 x 10-6 K-1 – (25 ÷ 600 °C) 14 x 10-6 K-1
Melting point	1420 °C
Density	8,4 g/cmc
Vickers hardness	188 HV10
Percentage elongation at fracture	9 %
Yield load strength	(Rp0.2) 360 MPa
Modulus of elasticity	190 GPa
Ions release in 7 days	1,6 μg/cm2
Maximium cooking temperature	900°C
Colour	White
